PlantQuest Infrastructure Management Plans

PlantQuest approached Jason during their initial set up period, to help develop the plans that would be used in their newly developed and unique plan-based application for on-site management of assets, alarms and industrial workflows. Aimed at life sciences, oil and chemical, industrial manufacturing and other mission critical industries, the plan is queried on an interactive tablet-based application, providing the user with locational, wayfinding and specific asset management information. Jason was involved in early development prototypes, creating plans that were clearer and simpler to read, though still accurate. Typically, CAD plans are often visually noisy, with little visual hierarchy and carry information unnecessary to the task ahead.

Note: Images not to scale.
